DSLRKIT Gigabit 8 Ports Passive PoE Switch Injector Ethernet NO Power Adapter

DSLRKIT DIM7P1UKG&nbsp;Passive PoE Injector Switch<br><br>ALL Gigabit Ethernet Power supply not included<br>Supports 12~57V DC power supply (Maximum current 4 amps)<br>DC IN port 5.5X2.1mm, inside positive (+)&nbsp; outside&nbsp; negative (-)<br>8 Ports (1Uplink,&nbsp;7 PoE)10/100/1000Mbps Midspan Mode-B Unsolicited Power(4,5+/7,8-)<br><br>This item do not include the power adapter,&nbsp; you need to buy an extra power adapter according to your requirement. So it only suitable for PoE professional customers.8 Ports (1Uplink, 7 PoE)10/100/1000Mbps Midspan Mode-B Unsolicited Power(4,5+/7,8-)<br> Please&nbsp;select&nbsp;the&nbsp;correct&nbsp;Power&nbsp;adapter&nbsp;by&nbsp;POE&nbsp;device， <br> 802.3af&nbsp;(802.3at&nbsp;Type&nbsp;1)&nbsp;PoE&nbsp;device,&nbsp;We&nbsp;suggest&nbsp;DC&nbsp;48V&nbsp;power&nbsp;adapter. <br> 802.3at&nbsp;Type&nbsp;2&nbsp;PoE+(plus)&nbsp;device,&nbsp;We&nbsp;suggest&nbsp;DC52V&nbsp;power&nbsp;adapter. <br> Please&nbsp;refer&nbsp;to&nbsp;the&nbsp;Wikipedia&nbsp;"Power&nbsp;over&nbsp;Ethernet"&nbsp;section,&nbsp;under&nbsp;the&nbsp;"Standard&nbsp;implementation"&nbsp;paragraph. <br><br>If your camera is with word “12V/PoE” as this picture shows, then please select 48V(or 52V)&nbsp;Power Adapter, do not select 12V Power Adapter.<br><br> Because "12V/PoE" means it can offer power supply to camera via 12V DC port or 48V PoE Ethernet port:<br>This is an Passive Power Over Ethernet of 8&nbsp;port 10/100/1000Mbps-T Ethernet switches, including 7 unsolicited PoE Ethernet ports and 1&nbsp;Uplink ports. <br>DC port apply 12~57V power supply adapter(not included),<br>any one of the 7 port can provide output power, each Ethernet port can provide network transmission speeds of up to 10/100/1000Mbps , with Cat5 / 5e / 6 network cable.<br>Please&nbsp;do not connect any "NONE PoE gigabit ethernet device and Uplink device"&nbsp;on "PoE 1X~PoE 7X" port, this will damage your device..<br>NONE PoE gigabit ethernet device and Uplink device can only access&nbsp;"8x" port, Please do not access&nbsp;"PoE 1X~ PoE 7X", this will damage your device.<br>Features:<br>8 x 10/100/1000Mbps Auto-negotiation Fast Ethernet RJ-45 ports with 7-Ports PoE function(port 1-port 7)<br>Switch Controller Chips Realtek RTL8370N<br>Midspan Mode-B Unsolicited Power(4,5+/7,8-)<br>Per port Maximum current: 0.84A<br><br>Supports 12~57V DC power supply&nbsp;&nbsp;<br>Each port supports auto MDI/MDIX, so there is no need to use cross-over cables.<br>Full/half duplex transfer mode for each port.<br>Power Input<br> Supports INPUT 12-57V DC power supply<br> Power DC port 5.5 x 2.1mm,inside positive (+)&nbsp; outside&nbsp; negative (-)<br>PoE Power on RJ45<br> Power +: pin 4 &amp; pin 5 ; Power -: pin 7 &amp; pin 8<br> DC Output: 12-57V, Per PoE port Max 0.84A,<br>Product Dimensions 200mm W x 95mm D x 30mm H<br><br>Temperature<br> Operation Temperature:0 ~40℃ (32 ~104℉)<br> Storage Temperature: -40 ~70℃(-40 ~158℉)<br>Humidity&nbsp;<br> Storage Humidity 5%~90% non-condensing, Operating Humidity 10%~90% non-condensing<br>Filtering Address Table: 2K entries per device<br>Packet Filtering Forwarding Rate<br> 10Mbps Ethernet: 14,880/pps<br> 100Mbps Ethernet: 148,800/pps<br> 1000MBase-T Ethernet: 1,488,000/pps.<br>MAC address Learning:&nbsp; Automatic update<br>Transmission Method: Store – and- Forward<br><br>Item Included:<br>DSLRKIT DIM7P1UKG&nbsp;8pots 7PoE&nbsp;ALL Gigabit&nbsp;PoE switch x1<br>(Power supply not included)

• Supports 12~57V DC power supply (Maximum current 4 amps)
• 8 Ports (1Uplink, 7 PoE)10/100/1000Mbps Midspan Mode-B Unsolicited Power(4,5+/7,8-)
• This item do not include the power adapter,  you need to buy an extra power adapter according to your requirement.
• 8 x 10/100/1000Mbps Auto-negotiation Fast Ethernet RJ-45 ports with 7-Ports PoE function(port 1-port 7)
